iData 70 Mobile Computer

iData
Availability:

Pre Order - 2 to 4 weeks


iData 70 mobile computer provides a perfect balance of large screen and single handed operation, with more stabilized high speed data collection and transmission.

  • OS: Android 5.1
  • CPU: 1.3 GHz Quad Core Processor
  • Memory: 16GB ROM + 2GB RAM
  • Connection: WIFI, 4G/3G/2G & Bluetooth 4.0
  • Display: 4 inch, 800 x 480
  • Camera: 8MP
  • Battery: 3.8V 5000 mAh Rechargeable Battery
  • Barcode Scanner: 1D Laser or 2D Area imager

Clear

Overview

More efficient with extremely speedy data collection

  • The latest industry-level scanning engine ensures high sensitivity and accuracy.
  • Streamlined systematic data collection process results in an increased scanning speed.
  • Scanning and verification can be done in one step, thanks to the new design of ergonomic scanning angle.
  • Data collection with NFC, GPS positioning, high-definition camera or by other means is supported, so as to enable professional, precise and efficient collection of business data.

Efficient and timely data transmission

  • Seamless network selection and connection according to needs with 4G wireless communication supported by all network operators helps to realize more efficient business data connection and communication.
  • The 5th generation Wi-Fi technology (802.11ac) is used to increase the transmission speed by 300%, enable free switch and transmission between two channel frequencies, and make the signal stronger and more stable.
  • Bluetooth 4.0 transmission technology features low power consumption and fast connection, perfectly matched with mainstream portable printers.

Long-life battery supports full-day operations

  • 5000mAh li-polymer safe battery is used to support full-loaded operations of up to 24 hours.
  • The use of low-energy-consuming chipset and optimized system result in more efficient and less energy-consuming operations.
  • Fast recharging technology is adopted to shorten the recharging time by 40% and further extend the battery life.

Applications
  • Logistics
  • Warehousing
  • Retail
  • Healthcare
  • Manufacturing
  • Utilities and Public Service
  • Others



Downloads

Brochure



System Configuration

CPU: High-performance quad-core  1.3 GHz processor
Operating System: Android 5.1
Memory:

16 GB ROM+2 GB RAM

Expansion Slot: Optional Mini SD card, up to 32 GB
Display: 4 inch, 800 x 480
Touch Panel: Industrial-grade capacitive panel
Camera (Optional): 8 MXP autofocus camera in the back side , autofocus lens, LED flash
Exit Window: Corning® Gorilla® glass
Keypad: 20 front keys, 4 side keys
Battery: 3.8 V 5000 mAh rechargeable lithium polymer battery
Audio: Built-in microphone /Micro USB
Notification: Vibrator alerts/LED/Audio notification
Vibration Motor: Built-in programmable vibration motor

Operating Environment

Development Tools: Android SDK+ JDK+Eclipse
Programming Language: Java
Operating Temp.: -10℃ to 50℃ (14℉ to 122℉)
Storage Temp.: -20℃ to 60℃ (-4℉ to 140℉)
Relative Humidity: 0 to 95% (non-condensing)
Drop Specification : 1.2-meter drops to concrete ground
Tumble Specification: 150 0.5-m tumbles (500 hits)
Sealing: IP65
Electrostatic Discharge: Conforms to ± 15 kV air discharge, ± 8 kV direct discharge

Structural Parameters

Dimensions (LxWxD): 159 mm×71 mm×20 mm
Weight: 262 g (battery included)

Communication Transmission

Wireless Voice
Communication :
GSM 850/900/1800/1900MHz, CDMA BC0(800MHZ),
WCDMA band 1, TD-SCDMA band 34/39,
TDD-LTE band 38/39/40/41, FDD-LTE band 1/3
Data service: GPRS/EDGE/ EVDO /HSPA+/TD-SCDMA/TDD-LTE/FDD-LTE
Wireless LAN:

(Optional) Wi-Fi 802.11a/b/g/n
(Optional) Wi-Fi 802.11a/b/g/n/ac

Bluetooth: Bluetooth 4.0+EDR, Supporting BLE
GPS : Supporting GPS / AGPS/Glonass

Input/Output Ports

USB Port: 1 ( Micro USB port)
Serial Port: 1

1D Laser Scanner

Optical Resolution: ≥4 mil
Scan Depth of Field: 3.81 cm – 60.98 cm
Scan Angle: 47°± 3° (Standard)
Scan Speed: 102 ± 12 scans/sec. (Bidirectional)

1D / 2D Area Imager

Optical Resolution: ≥3 mil
Scan Angle: Omnidirectional
Scan Speed: 300 scans/sec.

NFC RF identificationNFC

Frequency: 13.56 MHz
Reading Distance: Within 10 mm
Protocol: ISO14443A/14443B/15693

Accessories

Standard: Battery, Wrist strap
Optional: Battery with NFC, USB, Power adapter, Charging stand, DC charging line
