GT-7120 Desktop 2D Barcode Scanner
Availability:
2 in stock
Overview
- Planar CMOS sensor
- 32-bit ARM MCU processor
- Resolution: 1D 3MIL
- Scanning speed: 300scans/sec;
- Decoding capability: All standard 1D & 2D Bar codes
6 months warranty *no on-site support (customer need to send to us for technical support)
| Weight | 0.95 kg |
|---|
| Material | ABS+PC+TPU |
| Size | L*W*H: 153mm*109mm*97mm |
| Power Supply | DC 5V/420mA |
| Weight | 310±5g (without cable) |
| Performance Parameters | |
| Support Interface | USB |
| Sensor | Planar CMOS sensor |
| Light Source | white LED (lighting) |
| Processor | 32-bit ARM MCU |
| Decoding Capability | 1D version: Codabar,Code39,Code32,InterLeaved 2 of 5(24bit),Industrial 2 of 5( Industrial25),Matrix 2 of 5,Code93,Code128,Gs1-128,UPC-A,UPC-E,EAN/JAN-8,EAN/JAN-13,GS1 DATABAR(RSS14),GS1 DATABAR Limited, Gs1databar Expanded |
| 2D version: QR, MicroQR, PDF417, Data Matrix, AZTEC | |
| Resolution | 1D 4MIL, 2D QR8 3MIL, PCS45% |
| Depth of Field | 4MILÂ CODE39:Â Â Â Â Â Â 0–4Â Â CM 13MILÂ UPC-A :Â Â Â Â Â Â 0–16Â CM 15MILÂ QRÂ Â Â :Â Â Â Â Â Â 0–14Â CM 1D code from Alipay 0–24 CM 2D code from Alipay 0–47 CM Available for Stationery small barcode & wide barcode |
| Scanning Speed | 300scans/sec |
| Scanning Method | Auto-sensing |
| Scanning Area | 5 * 5 cm² — 20 * 20 cm² |
| Prompting Mode | Buzzer, indicator light (LED) |
| Printing Contrast | No lower than 35% |
| Scanning Angle | Roll 0-360°, pitch ±65°, yaw ±60° |
| Environment Parameters | |
| IP Grade | IP 54 |
| Operating Temperature | 0 to 50 ºC / 32 to 122 ºF |
| Storage Temperature | 0 to 50 ºC / 32 to 122 ºF |
| Operating Humidity | 5 – 95% (non-condensing ) |
| ESD Protection | 15kv air discharge |
| Shock Resistance | 1m free fall on concrete surface |
